USSC 13
1
1
2
2
3
3
4
4
A A
B B
12 1/8
11 3/4
10 1/16
EXHAUST OULET
3" DIA.
COMBUSTION
AIR INTAKE
1 7/8" DIA.
10 1/16
11 5/8
12
EXHAUST OUTLET
3' DIA
COMBUSTION
AIR INTAKE
1 7/8" DIA
3" PL Vent (12" Long)
Inner Wall Thimble
Outer Wall Thimble
3" PL Vent (12" Long)
3" PL Tee w/ Cleanout
3" PL Vent (12" Long)
3" PL Vent 90° Elbow
3" PL Vent Termination Cap
Note: Always check dimensions on unit before cutting hole in wall
Dimensional tolerance
±1/4”
*For illustrations purposes only
A MINIMUM OF 3 VERTICAL
FEET OF PIPE OUTSIDE THE
HOME IS REQUIRED!
1
1
2
2
3
3
4
4
A A
B B
12 1/8
11 3/4
10 1/16
EXHAUST OULET
3" DIA.
COMBUSTION
AIR INTAKE
1 7/8" DIA.
10 1/16
11 5/8
12
EXHAUST OUTLET
3' DIA
COMBUSTION
AIR INTAKE
1 7/8" DIA
APCI1406- LEG UNIT
