Model D1996FI, SS, and HNDL
(DW 95FI)
Page
DescriptionFig
. Part No. Notes
Date
2000-06
Qty
11
1996SS AND HNDL CASING AND RELATED PARTS
1 1 80 583 53 Sound insulation
2 1 80 600 41 Sound insulation profile
3 1 80 575 26 Guard plate
4 89 003 52 Screw RTS ST 4.2x13
4 1 80 707 43 Felt, kick plate
5 1 80 597 58- Kick plate, low -0, -29
2 89 009 44- Screw, kick plate -0, -29
6 1 80 706 15 Sealing strip
7 1 80 571 00- Lower cover -S-0, -S-29, -95
2 89 003 52 Screw RTS ST 4.2x13
4 80 097 69- Plug for decor frame -0, -33
8 1 80 706 12 Sound insulation
9 1 80 584 86 Drip protection for guard plate
10 2 80 575 49 Bracket, kick plate
11 2 80 575 50 Spring, kick plate
2 89 003 27 Screw RTS ST 4.2x13 FZB T20
