Model D1996FI, SS, and HNDL
(DW 95FI)
Date
2000-06
Page
6
ELECTRICAL FUNCTIONS
ELECTRICAL SUPPLY
The machines are wired for connection to a single-phase, 120V, 15A supply, with a heater power of
1400W, giving a total power requirement of 1600W.
VALUES FOR WIRING DIAGRAMS
Resistance values at 68° F (+/-5°F), 20° C (+/-3°C)
(Values within +/- 10% is normal.)
AP Drain pump 120V, 60 Hz, 25.5 ohm
BB Illumination switch
BE Internal Illlumination 120V, 51 ohm
CP Main pump 120 V, 60 Hz, Main = 10.5 ohm, Aux = 14.5 ohm
KD Combi-dispenser 120 V, 0.31 ohm
EL Heating element 120 V, 1400 W, 10 ohm
F Filter 680 K ohm (1-2,3-4)
IV Inlet valve 120 V, 9.93K ohm
FL Fan 120 V, 0.25K ohm
LB Door switch
LU Door
N Level switch
P Control unit
T Thermostat 19–25 K ohm
TB Pushbutton switch
TTE Temp. thermistor 18–25 K ohm
WAX Wax motor 1.5–3.0 K ohm
VMG Rinse ag sensor
OB Overflow switch
