Model D1996FI, SS, and HNDL
(DW 95FI)
Page
Date
2000-06
29
SERVICE INFORMATION
Product: DW95 Date: 98-03-12
TOPIC: DOOR SPRINGS
There are three different sets of door springs, as defined below:
Part Number Machine Weight Capacity Color Coding
80 584 91-77 For all standard machines 9 lbs. none
80 602 32-77 For integrated and 12 lbs. yellow
fully-integrated machines
80 713 23-77 Heavy-duty for wooden panels, 22 lbs. red
available as accessory part
Color code
