Asko D1996FI - Page 13

Model D1996FI, SS, and HNDL
(DW 95FI)
Page
DescriptionFig
. Part No. Notes
Date
2000-06
Qty
13
CONTAINER AND RELATED PARTS
2 1 80 600 65 Sealing strip, left
1 80 600 66 Sealing strip, right
2 80 600 38 Insulation, bottom outer
3 1 80 574 89 Tub seal
4 2 80 579 78- Ball catch -77
5 2 80 586 38- Ball bearing holder, guide rail -77
6 8 80 579 77 Ball bearings
7 2 80 579 79- Basket stop -77
8 2 80 570 52 Guide rail
9 1 80 600 33 Sound insulation
10 4 89 011 10 Screw + O-ring A2-M6x12 T30
11 1 80 570 77 Heating element 1400 W 120 V
1 80 602 58 Cable holder For heating
2 80 023 70 Protection collar, heating
12 1 80 584 95
13 2 80 583 52 Sound insulation
14 1 80 701 42 Cable holder
15 1 80 025 79 Thermostat Overheat protection
16 1 80 597 61- Strip side, left -0, -29, -95, for D1996SS & HNDL
1 80 59762- Strip side, right -0, -29, -95, for D1996SS & HNDL
4 89 006 46 Screw A4RTS 4.2x13 T20
2 89 003 52 Screw RTS ST 4.2x13
17 2 80 706 14 Sealing strip for D1996SS & HNDL
18 1 80 575 23 Base pan
2 89 011 04 Screw A2-MRT-TT 4x8 T20
19 2 80 584 91- Door springs compl. -77, for D1996SS & D1996HNDL
2 80 602 32 Door springs compl., integrated -77, D1996FI
2 80 713 23- Door springs compl., integrated -77, heavy-duty for D1996FI (optional)
20 1 80 704 95 Mount, inlet valve
2 89 003 27 Screw RTS ST 4.2 x 13 FZB T20
21 1 80 602 55 Mount, electrical connection
22 1 80 599 91 Cable holder
23 1 80 069 48 Grommet
24 1 80 585 58 RFI filter
25 1 80 502 51 Terminal block 3-pole
1 89 003 57 Screw, terminal block RTS ST 4.2x25 FZB T20
1 89 021 31 Screw, grounding terminal bl. MRT-TT 4x6 FZB T20
1 89 014 13 Washer AZ 4.3 FZB
26 4 80 721 19 Reinforcement washer
27 4 80 570 62 Leveling leg M10x100, 8.8 FZB
28 4 89 011 56 Nut M6M10 BH8 FZB
29 2 80 519 57 Slide foot, rear only
