Model D1996FI, SS, and HNDL
(DW 95FI)
Page
DescriptionFig
. Part No. Notes
Date
2000-06
Qty
15
D1996FI DOOR
1 1 80 600 21 Fan, complete
2 1 80 527 78 Wax motor
3 1 80 585 01 O-ring
4 1 80 579 63- Air channel, turbo dry -S
5 1 80 722 97 Nozzle for air channel (See page 28)
6 1 80 722 98- Strut for nozzle -29
7 1 88 011 20 Inner door, compl.
4 89 021 20 Screw A2-MKFT 5x10-TT FZB
8 1 80 579 64 Lock ring, fan casing
9 1 80 584 84 Cover plate, fan
2 89 020 85 Screw, fan cover plate A2-PTK 40x10 WN1452
10 1 80 706 79- Combi-dispenser -77
6 89 020 87 Screw PTK 40x14 WN1452 FZB
1 80 719 17 Rinse aid cap
1 80 719 18 Combi-dispenser lid Incl. seal and spring
11 1 80 575 25 Hinge, left
1 80 575 24 Hinge, right
2 80 575 30 Hinge screw
2 33500262 Nut, hinge bearing, locking Locking 4 BH8 FZB
12 2 80 579 48 Slide washer, hinge bearing
13 1 80 715 87 Holder, cable harness
1 89 021 31 Screw, cable harness holder MRT-TT 4x6 FZB T20
14 1 80 602 54 Door seal, lower L=555 mm
15 1 80 579 85 Brace stand
2 89 006 46 Screw, lower stay A4 RTS 4.2x13 T20
18 1 80 579 86- Outer door -PT-0, PT-29
6 89 006 46 Screw A4 RTS 4.2x13 T20
2 89 003 27 Screw, lower stay RTS ST 4,2x13 FZB T20
2 80 703 50- Plug -0, -33
19 1 80 702 94 Sound insulation, short
20 1 80 703 63 Adjusting frame, complete
