Model D1996FI, SS, and HNDL
(DW 95FI)
Page
DescriptionFig
. Part No. Notes
Date
2000-06
Qty
23
1996HNDL CONTROL PANEL
1 1 80 722 67- Decor insert -95
2 1 80 706 50 Spring
3 1 80 706 44- Pushbotton -81
4 1 80 706 43- Main switch casing -81
5 1 80 575 47 Main switch
6 1 80 710 77 Hose 9x13x295
7 1 80 706 47 Lock casing
8 1 80 706 45- Masking -77
9 1 80 706 48 Lock washer
10 1 80 706 49 Lock catch
1 89 011 04 Screw A2-MRT-TT 4x8 T20
11 1 80 710 49 Protective film
12 1 88 012 03 Control unit
1 80 600 76 Contact cover
2 89 020 53 Screw PTK 40x45/15 FZB
2 89 020 87 Screw PTK 40x14 WN1452 FZB
13 1 80 597 67 Thermistor
15 1 80 729 40- Decor insert -81
16 1 80 706 40- Panel -K -69
2 89 020 85 Screw A2-PTK 40x10 WN1452
17 1 80 724 35 Handle L=560 mm
2 80 722 69 Tin plate for handle
18 2 80 724 36 Cross brace, handle
2 80 724 39 Screw MC6S M5x45 8 8 FZB
19 2 80 724 38 Bushing handle
20 2 80 724 37- End plugs for handle -33
21 1 80 734 64 Cable harness complete
1 80 730 96 Use and Care Guide
