Asko D1996FI - Page 25

Model D1996FI, SS, and HNDL
(DW 95FI)
Page
DescriptionFig
. Part No. Notes
Date
2000-06
Qty
25
DISHWASHING SYSTEM
1 1 80 713 37- Cup shelf, wine glasses -36
2 1 80 011 99- Upper basket, w/wheels -36, with cup shelf
1 80 727 64- Glass support, adjustabe -36
3 1 9- 570 58- Knife tray , upper cutlery basket -36
4 1 80 533 76- Upper cutlery basket -36
5 1 80 575 05- Knife stand, upper cutlery basket -77
6 1 80 725 50- Cup shelf, divided -36
7 1 80 575 02 Glide mount 1 for upper cutlery basket
8 1 80 584 53 Glide mount 2 for upper cutlery basket
9 1 80 575 03- Grommet, spray pipe, upper -77
10 1 80 575 00 Upper spray pipe
11 1 9- 575 04- Grommet, spray pipe, lower -77
12 1 80 575 36- Lock ring, air break -77
13 1 80 585 04 O-ring, inlet air break
14 1 80 575 14 Air break
15 1 80 597 40 Filter, upper part
16 4 80 584 98- Basket wheel, upper -77
18 1 88 010 89- Cutlery basket -77
19 1 88 012 00- Lower basket -36
20 8 80 095 16- Basket wheel, lower -77
21 1 80 584 93- Lower basket insert -36
22 1 80 703 04 Outlet hose
23 1 80 726 95 Spray arm, upper
24 2 89 012 62 Nut, spray arm bearing
25 2 80 520 95 Washer, spray arm bearing
26 2 80 570 70- Spray arm bearing -77
27 1 80 570 68- Spray pipe bearing, upper -77
28 1 80 570 63 Spray pipe
29 2 80 521 89 Hose clip, inlet valve 17.0-706
30 1 80 585 02 Rubber hose, inlet valve
31 1 80 721 23 Inlet valve
2 89 020 87 Screw PTK 40x14 WN1452 FZB
32 1 80 726 92 Spray arm lower
33 1 80 570 67- Spray pipe bearing, lower -77
34 1 89 017 55 O-ring, lower spray pipe bearing
35 1 80 570 69 Nut, spray pipe bearing
36 2 80 574 84 Hose, circulation pump
37 4 80 520 97 Hose clip, circ. pump hose 44.0-708
38 1 80 550 95 Rubber buffer, circ. pump
39 1 80 710 24 Level switch (pressure)
40 1 80 570 53 Float, base pan
41 1 80 600 68 Microswitch float
42 1 80 585 00 Rubber hose 5x8x340
43 1 88 011 23- Base pan, sump -77
44 1 80 585 03 O-ring, base pan, sump 109.5x3
45 1 80 025 84 O-ring, outlet pump 49.5x3
46 1 80 574 87- Cover plate -33
47 1 80 720 32 Outlet pump
48 1 80 522 39 Hose clip 31.6-708
49 1 80 574 88 Lock ring, bottom well, sump
50 1 80 584 54 Cover plate
51 1 80 579 72- Filter basket, coarse -77
52 1 80 574 86- Insert, filter basket -77
53 1 80 712 50 Circulation pump
