3. Lean the dishwasher forward a little and adjust the rear foot with the screw at the front of the
dishwasher. Turn clockwise to lower or counterclockwise to raise.
4. Adjust the front feet by turning them clockwise to raise and counterclockwise to lower the
dishwasher.
5. Verify there is an air gap of at least 1/8'' between the underside of the countertop and the top
edge of the dishwasher.
6. Slide the dishwasher into place.
• Pull the supply and drain hoses and the power cord when sliding the dishwasher into place.
• Check that the drain hose has no kinks or sharp bends. Also check that there is nothing that
can damage the hoses.
• Check that the machine is installed such that the door opens freely, otherwise door lock
functionality may be disrupted.
7. Make any final adjustments to the feet (the dishwasher may lean no more than 1/4'') and tighten
the lock nuts on the front feet.
46
Installation instructions
