NOTE!
Framed cabinets require additional finished filler material behind the face frame for a proper
installation. A minimum 3½” (89 mm) finished return is required on all sides of the opening.
Frameless
cabinetry
Filler
Framed
cabinetry
If the dishwasher is built-in, the surrounding furnishings must be resistant to any condensation from
the dishwasher.
Accessory
Buy an accessory kit for freestanding installation (two side panels, a countertop, and two anti-tip
brackets). If the dishwasher is placed so that one of the sides is visible, side panels must be fitted.
If the dishwasher is completely freestanding, both side panels, a countertop, and anti-tip brackets
must be fitted. Accessories can be purchased from where you bought the dishwasher.
Fit the protective film
Mount the protective film beneath the countertop and up around the edge. The function of the
protective film is to protect the countertop from moisture. (The protective film is in the enclosed
plastic bag.)
NOTE!
The surface to which the protective film is fitted must be clean and dry.
Adjust the height and slide the dishwasher into place
1. Start by measuring the height from the floor to the bottom edge of the countertop.
2. Measure the height from the floor to the top edge of the dishwasher.
45
Installation instructions
