28
Installation
Suggestions on positioning the
dishwasher
The dishwasher can be built in, fully freestanding
or semi-freestanding.
CAUTION!
Connection to electricity, water and drainage
must be carried out by a suitably qualied per-
son.
A. Built-in
The dishwasher can be built in under a worktop
with a working height of 820 - 870 mm. The width
measurement must be at least 600 mm. For
additional measurements, see picture.
Built-in installation
Min 823
Min 560
600
135-185
50
50-105
596
820-870
520
560
With nut and sliding protection mounted
Recommended measurements
**
*
*
**
* *
100-
150
B. Semi-freestanding
If the dishwasher is positioned so that either side
is visible, a side panel can be tted.
These accessories can be purchased where you
purchased the dishwasher.
C. Freestanding
A freestanding dishwasher must be tted with anti-
tilt. This comprises two fastening irons which are
screwed into place as illustrated.
The dishwasher is then pushed in so that the
fastening irons grip onto the rear feet. The
dishwasher cannot now tilt in the event a load is
placed on the open door. If the dishwasher is to
be fully freestanding, both side panels and the
work top should be tted. These accessories
can be purchased where you purchased the
dishwasher.
Freestanding installation
455-475
600
413
CAUTION!
A fully freestanding dishwasher must be tted
with anti-tilt.
Tip!
A machine with side panels and a counter top
(freestanding) can, of course, also be installed
as a built-in unit.
Remove transport protection devices A and B as
illustrated.
D. Machines with wooden door
Stronger door springs are available for purchase
for machines with a tted wooden door. Springs
are available for various weights and sizes of
wooden door. Door springs can be purchased
from the retailer who sold you the dishwasher.
