13
INSTALLATION
ELECTRICAL INSTALLATION
The electrical installation must be carried out by
a qualified tradesman.
The installation is made using fixed wiring and
a multi-pole breaker.
Connections on delivery
The machine is supplied for 3-phase, 400 V, hea-
ting power 2500/2620 W (see type label) and
fused at 10 A.
If an earth fault breaker is installed, it should
be of type A.
Rewiring to single-phase
The machine can be rewired to single-phase, 10
or 16A. For rewiring to single-phase a 3-wire ca-
ble and wall plug are required. Rewiring shall be
carried out in accordance with the rewiring dia-
gram (supplied with the machine, in the front
beam).
• 1-phase, 230 V, 50 Hz, heating power 1900
W, fused at 10 A (T700/720/780).
• 1-phase, 230 V, 50 Hz, heating power 2500/
2620W, fused at 16A (T760).
IMPORTANT
Electrical connections/rewiring must be carried
out by a qualified tradesman.
T780 (Condenser tumble drier with display):
For the machine to show the correct remaining
drying time, after rewiring select the Low heating
power (or High if you rewire to 3-phase).
Do this:
Switch off the mains power button,
, and
press it again to restart the machine.
Press the
Enter
button 5 times, then press the
P2
button 5 times. These 10 button presses must be
done within 15 seconds.
Within 3 seconds of the last button press select
Low with the
buttons.
Joint connection of the tumble drier and an
ASKO washing machine
NOTE
Joint electrical connection as described below
must be carried out by a qualified tradesman.
To ensure even loading of the phases when in-
stalling the tumble drier jointly with a single-phase
ASKO washing machine, the phases should be
connected like this:
Tumble drier:
Terminal labelled L1 to phase 1.
Terminal labelled L2 to phase 1.
Terminal labelled L3 to phase 2.
Washing machine:
Terminal labelled L to phase 3.
