Asko T780 - Front Rail

76
SERVICE
2
3
4
2
BOTTOM
Changing the bottom
1. Remove the condenser housing in accordance
with the section " Condenser housing - remo-
ving..."
2. Early models: the hole is marked out on the
bottom.
3. Cut off the rivets between the bottom and
side panels.
4. Install 6 clips along the bottom edge of the
side panels.
5. Early models: Drill a 6.5 mm diameter hole
in the bottom at the marking.
6. Screw the side plates to the bottom from un-
derneath.
7. Install the condenser housing in accordance
with the section " Condenser housing - in-
stallation...".
FRONT RAIL
Changing the front rail
1. Remove the panel in accordance with the sec-
tion "Panel - removing...".
2. Early models: the hole is marked out on the
front rail.
3. Remove the rivets with a screwdriver and flat-
ten with a polygrip.
4. Early models: Drill a 5 mm diameter hole in
the front rail at the marking.
5. Secure the new front rail.
6. Install the panel in accordance with the sec-
tion "Panel - installation...".
