FRONT PANEL
Removing front panel
1. Remove the three screws at the rear edge and
lift off the top cover.
2. Remove the three screws that secure the lo-
wer hinge and twist it free, lift off the front
door.
3. Unscrew the 4 screws that secure the front fra-
me to the front panel.
4. Unscrew the 4 screws that secure front panel
to the side panels.
5. Unscrew the 2 screws that secure the bottom
edge of the front panel.
6. Lift off the front panel.
Installing front panel
7. Put the front panel into position.
8. Secure the 4 screws from the inside in the side
panels.
9. Put the front door back on, keep it in posi-
tion with the aid of the door magnet, and se-
cure the hinge.
.
10. Secure the 2 screws that secure front panel at
the bottom edge.
IMPORTANT
Don't forget the 2 star washers.
11. Secure the 4 screws that secure the front fra-
me to the front panel.
12. Fit the top cover.
IMPORTANT
Don't forget the 2 star washers for the outermost
screws.
