SERVICE
Changing the fixing clip for the bottom cover
(female)
1. Remove the bottom cover.
2. Squeeze the snap fasteners and pull or push
out the clip.
3. Install a new clip.
4. Install the bottom cover.
Changing the fixing clip for the bottom cover
(male)
T700/760, Left T720/780:
1. Remove the bottom cover.
2. Squeeze the snap fasteners and pull or push
out the clip.
3. Install a new clip.
4. Install the bottom cover.
Right T720/780:
1. Remove the bottom cover.
2. Remove the condenser housing in accordance
with the section "Condenser housing - remo-
ving...".
3. Squeeze and pull or push out the clip.
4. Install a new clip.
5. Install the condenser housing in accordance
with the section "Condenser housing - instal-
lation...".
6. Install the bottom cover.
