27
CONSUMPTION VALUES
PROGRAM
MATERIAL
LOAD
ENERGY CONSUMPTION PROGRAM TIME
(approx. kWh)
800 rpm - 1600 rpm
(approx. minutes)
800 rpm - 1600 rpm
P1 Cotton, linen max (5,0 kg) 4,1 - 3,4 110 - 100
Extra dry
Cotton, linen max (5,0 kg) 3,9 - 3,1 100 - 85
P2
Non-iron Polyester/ max (2,5 kg 1,7 - 80 -
Cupboard dry Cotton
Cotton, linen max (5,0 kg) 3,4 - 2,6 90 - 75
P3
Non-iron Polyester/ max (2,5 kg 1,5 - 70 -
Normal dry Cotton
Acrylics, rayon, max (2,5 kg) 1,7 - 80 -
acetates
P1 Cotton, linen max (5,0 kg) 2,4 - 2,0 70 - 60
Iron dry
T760
The following conditions apply for the consump-
tion values stated below:
Incoming air temperature: 20 °C
Incoming air humidity: 65 %
Drying temperature: Normal (
)
Low (
)
Heating element power: 2620 W
Cotton garments should, before tumble drying,
be spun at 800 to 1600 rpm (long spin drying)
in an ASKO washing machine.
Other garments (non-iron and acrylic) should,
before tumble drying, be spun at 800 rpm (short
spin drying) in an ASKO washing machine.
