58
SERVICE
2
3
3
2
3
Changing/cleaning the filter holder
1. Open the front door.
2. Pull out the filter holder and take out the
double filter.
3. Squeeze the snap fasteners inwards while at
the same time lifting the filter holder out of
the inner door.
IMPORTANT
Take care when lifting the filter holder out not to
damage it.
NOTE
Clean the filter holder if necessary.
4. Install it by first inserting the snap fasteners at
the top edge of the inner door.
5. Then push in the lower edge.
Changing the door switch
1. Remove the three screws at the rear edge and
lift off the top cover.
2. Bend up the protection.
3. Prise off the door switch with the aid of a
screwdriver.
4. Transfer the wiring to the new door switch
and connect it up.
5. Bend down the protection.
6. Fit the top cover.
IMPORTANT
Don't forget the 2 star washers for the outermost
screws.
