12 309421
Priming
12. Turn power switch ON.
Fig. 31
13. When paint starts to come out of prime tube, pull
and hold gun trigger, and turn Spray/Prime valve to
SPRAY.
When paint comes out of gun, release trigger.
Fig. 32
WASTE
SPRAY
pull and hold trigger
paint
ti6914a
NOTE: Motor stopping indicates pump and hose
are primed with paint.
14. Attach drain tube to suction tube.
NOTE: If pump does not prime after 30 seconds see
Pump Check Valves, page 10.
