Specifications
This appendix lists the specifications for your PL9670-Q2.
Standards Compliance:
•HomePlug® AV • IEEE 802.3, IEEE 802.3x, IEEE 802.3u,IEEE1901
Software Utility
System Requirements:
Microsoft Windows® 98 SE, 2000, ME, XP, Vista and windows 7(32bit)
Windows 7 (64-bit) ; operating systems
Network Protocol:
TCP/IP, CSMA/CA, TDMA (supported in the future)
Network Interface:
Two-ports 10/100 Mbps Ethernet (RJ-45)
PHY-Rate: Up to 500 Mbps
Distance: Over 300 meters
Operating Frequency:
2 to 70 MHz
Modulation Schemes: • Orthogonal Frequency Division Multiplexing (OFDM) • QAM
4096/1024/256/64/16 •QPSK •BPSK
EMI and Safety: • FCC Part 15 Class B •UL (US and Canada) •CE
Additional Protocols:
• Forward Error Correction (FEC) • Automatic Channel Adaptation
Power Supply:
• US Version: 100-120VAC • UK/EU Version: 220-240VAC
Surge Energy Rating: 4KV
Power Rating: • US Version: 120VAC 0.1A max, 60Hz • UK/EU Version:
220-240VAC 0.08A max, 50Hz
Security: 128-bit AES
