Simple Connection (Peer to Peer)
To share a simple connection between computers, attach one PL9670-Q2 device to
each computer.
NOTE: Do not connect the PlugLink-ETH-500 into a power strip, extension
cord, un-interruptible power supply (UPS), or surge protector. This may prevent
the unit from working properly or degrade the network performance.
Simple Broadband Connection
The following items are needed to share a Broadband connection with computers:
z One (1) PL9670-Q2 device attached to a standard cable, DSL, or wireless router;
z One (1) PL9670-Q2 device attached to each computer;
