Preventing Siphoning advice
• Cut discharge tube above water level of evaporator tray and direct end into
large pipe, allowing air break.
FALSE CEILING
TOP OF
BREATHER TUBE
END OF
DISCHARGE TUBE
WATER LEVEL
IN TRAY
AIR BREAK
Secure reservoir horizontally and using the inlet hose, connect firmly to drainage pipe.
2
Note direction of water flow.
6
Install pump drive unit in the evaporator unit under the condensate drain tray, or inside
the plastic conduit.
4
Fit breather tube to reservoir lid.
3
Installation
Ensure float is positioned in reservoir with magnet uppermost, the filter is in place
and the lid is clipped firmly onto reservoir.
1
Ensure that you securely position some anti-vibration material between the
Mini Aqua pump unit and any hard surfaces (inside evaporator or conduit).
5
3 4
FROM RESERVOIR
TO DRAIN
FALSE CEILING
EVAPORATOR COIL
CONDENSATE
DRAIN TRAY
CONDUIT
VINYL TUBE
ANTI-VIBRATION
(INSULATION)
HARD
SURFACE
EXAMPLE POSITIONS
1 INSIDE EVAPORATOR
2 INSIDE CONDUIT
15cm x 9mm o/d
x 6mm i/d vinyl tube
