Aspes APV1201 - Technical Specification


• If the appliance is being connected directly to the mains an omnipolar circuit-breaker
must be installed with a minimum opening of 3mm between contacts.
• The installer must ensure that the correct electrical connection has been made and
that it is compliant with safety regulations.
• The cable must not be bent or compressed.
• The cable must be checked regularly and replaced by authorised technicians only.
• The bottom surface and the power cord of the hob are not accessible after
installation.
Technical Specification
Cooking Hob
APV1201
Cooking Zones
2 Zones
Supply Voltage
220-240V~ 50-60Hz
Installed Electric Power
3000W
For circular cooking zones: diameter of useful surface area
per electric heated cooking zone, rounded to the neastest
5mm
Front: 190mm
Rear t: 155mm
Energy consumption per cooking zone or area calculated per
kg (EC electric cooking)
Front: 185.84Wh/kg
Rear:194.91 Wh/kg
Energy consumption of the hob, calculated per kg (EC
electric hob)
190,37 Wh/kg
Cooking Hob
APV2303
Cooking Zones
3 Zones
Supply Voltage
220-240V~ 50-60Hz
Installed Electric Power
5700W
For circular cooking zones: diameter of useful surface area
per electric heated cooking zone, rounded to the neastest
5mm
Left up: 15.5
Left down: 19.0
Right up: 30.0
Energy consumption per cooking zone or area calculated per
kg (EC electric cooking)
Left up: 195,29 Wh/kg
Left down: 183,85 Wh/kg
Right up: 180,86 Wh/kg
Energy consumption of the hob, calculated per kg (EC
electric hob)
186,66 Wh/kg
Cooking Hob
API2300I
Cooking Zones
3 Zones
Supply Voltage
220-240V~ 50-60Hz
Installed Electric Power
7200W
For circular cooking zones: diameter of useful surface area
per electric heated cooking zone, rounded to the neastest
5mm
Left up: 16.0
Left down: 18.0
Right up: 28.0
Energy consumption per cooking zone or area calculated per
kg (EC electric cooking)
Left up: 186,9 Wh/kg
Left down: 196,5 Wh/kg
Right up: 192,5 Wh/kg
Energy consumption of the hob, calculated per kg (EC
electric hob)
191,97 Wh/kg
