The touch controls are
difficult to operate.
There may be a slight film of
water over the controls or you
may be using the tip of your
finger when touching the
controls.
Make sure the touch control area is dry
and use the ball of your finger when
touching the controls.
The glass is being
scratched.
Rough-edged cookware.
Unsuitable, abrasive scourer or
cleaning products being used.
Use cookware with flat and smooth
bases. See ‘Choosing the right
cookware’.
See ‘Care and cleaning’.
Some pans make crackling
or clicking noises.
This may be caused by the
construction of your cookware
(layers of different metals
vibrating differently).
This is normal for cookware and
does not indicate a fault.
8. Failure Display and Inspection
If an abnormality comes up, the hob will enter the protective state automatically and display
corresponding protective codes:
Error Code for Ceramic hob
Problem
Possible causes
What to do
E0 & repeated
beep sound
warning.
Overheating protection:
the hob is over heated.
Stop cooking till the internal temperature back to
normal. Please contact after sales service to
check the hob if there is PCB failure.
E1
Open circuit failure of
thermocouple
Please contact after sales service.
Error Code for Induction hob
Problem
Possible causes
What to do
E1
Signal lost (PCB failure)
Please contact after sales service.
E2/E3
Abnormal high/Low input
voltage
Stop cooking and wait until input voltage back to
normal. If not please contact service center.
E4/E5/E6
Thermistor failure.
Please contact service center to repair.
E7
Abnormal high
temperature (dry
burning)
Cut off power, wait for 30min and switch on.
If still not working, please contact service.
E8/E9
Failure of IGBT sensor
Please contact service center to repair.
E0
IGBT Overheat
Check if the fan is still working. If not please
contact service center to repair.
EE
Display PCB failaure.
Please contact service center.
The above are the judgment and inspection of common failures.
ATTENTION! To avoid danger, please do not disassemble the unit by yourself!
9. Installation
9.1 Selection of installation equipment
Cut out the work surface according to the sizes shown in the drawing.
For the purpose of installation and use, a minimum of 5cm space shall be preserved
around the hole. Be sure the thickness of the work surface is at least 30mm. Please
select heat-resistant and insulated work surface material (Wood and similar fibrous or
hygroscopic material shall not be used as work surface material unless impregnated) to
