SAFE USE
UNSAFE USE
WARNING
Warning! Avoid reaching from within the wheelchair
To ensure the upright stability of the wheelchair, never reach for objects as this changes
the centre of mass and may cause the chair to tip over in the direction of reaching.
This warning relates to reaching in any direction outside the perimeter of the wheelchair.
11. ATTENDANT HANDBRAKE OPERATION
Activating Brakes
BRAKE: To engage brakes,
squeeze the handbrake in an
upwards direction.
Release
to go
Squeeze
to brake
11.1 HOW TO ACTIVATE BRAKES
RELEASE BRAKE: To disengage
brakes, release the handbrake.
Lock / Unlock
Press down
*CLICK*
Flip up
11.2 HOW TO LOCK CARER HANDBRAKES
LOCK: To engage brakes, squeeze
the handbrake in an upwards
direction. Press down on the switch
until it clicks, this will lock the brakes.
UNLOCK: To disengage brakes, flip
the switch upwards.
Lock / Unlock
Pull
backwards
10.3 HOW TO LOCK USER HANDBRAKES
LOCK: To engage brakes, push
the hand brake in a forwards
direction until it clicks, this will lock
the brakes.
UNLOCK: To disengage
brakes, pull the hand brake
in a backwards direction.
*CLICK*
Push
fowards
