ANTI TIPPERS MUST BE INSTALLED BEFORE USE
WCA848275
1
Twist and remove end cap (both sides).
3
The anti-tip wheel height range is
adjustable for improved mobility during
carer transportation.
2
Remove bolt and nut from tipper.
Slide tipper over tube.
Place bolt through tipper and tube.
Use the wrench to secure the nut.
TOOLS REQUIRED
Wrench (Included in box)
WARNING
IMPORTANT! Refer to section 10.6 for safe use of anti tippers when moving wheelchair
with and without a carer and on even or sloped terrain.
NOTE: Correct adjustment of the wheelchair is essential for the successful and safe use of this product.
NOTE: Should assistance be required, contact Aidacare.
Wheelchair is
steering/pulling
to one side
Ensure rear wheel quick-release axles are locked securely in place. This can
be checked by raising the rear wheels off the ground and pulling gently
outward at the wheel hub. When locked in place the locking balls should be
visible at the inner end of the axle sleeve.
Make sure the end user is able to evenly distribute his/her weight on
the wheelchair.
Make sure each wheel rotates freely.
Wheelchair is
moving slowly
Make sure the rear wheels are attached correctly to the frame.
Remove any hair or dirt from castor and rear wheel axles.
Make sure there is not too much weight applied to the castors, otherwise
adjust the centre of gravity.
Ensure user clothing is not interfering with movement of the rear wheels.
Ensure both brakes are disengaged.
Wheelchair does not
turn smoothly
Make sure the front fork bolts are not over tightened which can restrict front
castor wheel rotation.
Remove any hair or dirt from castor axles.
Ensure both brakes are disengaged.
Brakes are not
working properly
Check distance between tyres and brake foot is sufficient such that the
requisite amount of force can be applied to the tyre surface to stop it moving
when the brake is in the engaged position.
Wheelchair
cannot be opened
or folded easily
Clean the crossbar under the seat and apply some grease.
Check that nothing has become lodged under the seat or in and around the
cross bar mechanism.
Check foot plates are folded up.
15. TROUBLESHOOTING14. INSTALLING ANTI-TIPPERS
