4 5
English
Front Panel
Header
1
Front LAN LED
Header
1
Speaker(4pin) 1
SGPIO 3
Audio Header 1
COM Header 1
BMC_SMB1 1
OH/FanFail
LED
7 (only Fan Fail LED)
System BIOS
BIOS Ty pe 256Mb AMI UEFI Legal BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8 Support
- ASRock Rack Instant Flash
Hardware Monitor
Temperature - CPU Temperature Sensing
- System Temperature Sensing
Fan - CPU/Rear/Front Fan Tachometer
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
- CPU/Rear/Front Fan Multi-Speed Control
Voltage Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,
1.05V_PCH, +BAT, 3VSB, 5VSB
Support OS
OS Microso® Windows® (Server OS)
- Server 2012 R2 (64 bit)
- Server 2016 (64 bit)
Microso® Windows® (Client OS)
- Windows 10 (64 bit)
Linux®
- RedHat Enterprise Linux Server 6.8 (64 bit) / 7.4 (64 bit)
- CentOS 6.8 (64 bit) / 7.4 (64 bit)
- SUSE Enterprise Linux Server 11 SP4 (64 bit) / 12 SP3 (64 bit)
- Ubuntu 16.04 (64 bit) / 15.10 (64 bit)
- FreeBSD 11.2 (64 bit)
Virtual
- VMWare® ESXi 6.5
*Please refer to our website for the latest OS support list.
*On Ubuntu 16.04 (64bit) system, Intel Raid mode only supports UEFI
BOOT.
