TRX40D8-2N2T
8 9
English
No. Description
33 Intelligent Platform Management Bus Header (IPMB1)
34 BMC SMBus Header (BMC_SMB1)
35 Front LAN LED Connector (LED_LAN3_4)
36 Non Maskable Interrupt Button (NMI_BTN1)
37 M.2 Socket (M2_2) (Type 2230/2242/2260/2280/22110)
38 SPI TPM Header (TPM_BIOS_PH1)
39
Front VGA Header (FRNT_VGA1)
*For DIMM installation and conguration instructions, please see p.23 (Installation of Memory Modules
(DIMM)) for more details.
