1.7 Block Diagram
IPMI
COM header
ASPEED
AST2500
4x SATAIII
PCIeUSB
LPC
MAC
UART
RTL
8211E
MAC
VGA
RGMII
PCIe4.0 x8
1x USB2.0
PCIe2.0 x1
LPC/eSPI
SPI
D-Sub with Header
AMD
TRX40
BIOS
Switch
2xUSB3.1 Gen2, 2xUSB2.0
2xUSB3.1 Gen1,
2xUSB2.0
PCIe3.0x4
NCT6796D-
R
P_GPP [6]
PCIe2.0x1
PCIe2.0x1
C
D
DDR4
DDR4
DDR4 DDR4
A
B
3
rd
gen
AMD Ryzen™
Threadripper™
Series Processor
Socket sTRX4
TDP: max. 280W
G0
PCIe4.0x16
SLOT4 x8
PCIe4.0x16
PCIe4.0x16
2xUSB3.1 Gen1, 2xUSB2.0
NCSI
SLOT4 x8
SLOT7 x16
I225 I225
PCIe4.0x4
SLOT3 x16
PCIe4.0x8
2xUSB2.0
ASM
1061
PCIe2.0 x1
SLOT1 x8
SLOT5 x16
PS2 KB/MS
1xUSB3.1 Gen1, 1xUSB2.0
X710
-AT2
10GbE
10GbE
Oculink (BOM option)
TPM
TRX40D8-2N2T
AUX
PANEL
IPMB
Buzzer
PCIe4.0x4
2.5GbE
2.5GbE
P0
P2
G2
SATA [0:3]
P_GPP [12:15]
SATA [4:7]
P_GPP [8:11] SATA [8:11]
P_GPP [0:3]
P_GPP [4] P_GPP [5] P_GPP [7]
