2.5 Installation of Memory Modules (DIMM)
is motherboard provides eight 288-pin DDR4 (Double Data Rate 4) DIMM slots and
supports Dual Channel Memory Technology.
A single memory module should be installed in the Blue socket.
CPU1
A1 A2 B1 B2 C1 C2 D1 D2
1 DIMM
#
2 DIMMS
# #
4 DIMMS
# # # #
8 DIMMS
# # # # # # # #
1. It is not allowed to install a DDR, DDR2 or DDR3 memory module into a DDR4 slot;
otherwise, this motherboard and DIMM may be damaged.
2. For quad channel conguration, you always need to install identical (the same brand,
speed, size and chip-type) DDR4 DIMM pairs.
3. It is unable to activate Quad Channel Memory Technology with only one, two or three
memory module installed.
4. Some DDR4 1GB double-sided DIMMs with 16 chips may not work on this motherboard.
It is not recommended to install them on this motherboard.
