ASROCK 970DE3/U3S3 User Manual

4
3. BIOS SETUP UTILITY ......................................................... 32
3.1 Introduction ................................................................................ 32
3.1.1 BIOS Menu Bar ............................................................... 32
3.1.2 Navigation Keys ............................................................... 33
3.2 Main Screen ............................................................................... 33
3.3 OC Tweaker Screen................................................................... 34
3.4 Advanced Screen ...................................................................... 38
3.4.1 CPU Confi guration ........................................................... 39
3.4.2 Chipset Confi guration ...................................................... 40
3.4.3 ACPI Confi guration .......................................................... 41
3.4.4 Storage Confi guration ...................................................... 43
3.4.6 PCIPnP Confi guration...................................................... 44
3.4.6 Floppy Confi guration ....................................................... 45
3.4.5 Super IO Confi guration .................................................... 46
3.4.7 USB Confi guration ........................................................... 47
3.5 Hardware Health Event Monitoring Screen ............................... 48
3.6 Boot Screen ............................................................................... 49
3.7 Security Screen ......................................................................... 50
3.8 Exit Screen ................................................................................ 51
4. Software Support ......................................................... 52
4.1 Install Operating System ............................................................ 52
4.2 Support CD Information ............................................................. 52
4.2.1 Running Support CD ....................................................... 52
4.2.2 Drivers Menu ................................................................... 52
4.2.3 Utilities Menu ................................................................... 52
4.2.4 Contact Information ......................................................... 572

ASROCK 970DE3/U3S3 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	800, 1066, 1333, 1600, 1866 MHz
Processor socket	Socket AM3+
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II X2, AMD Phenom II X3, AMD Phenom II X4, AMD Phenom II X6
USB 2.0 connectors	3
Number of SATA II connectors	6
Number of SATA III connectors	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	-
I/O ports	1 x IR 1 x ATA133 IDE 1 x HDMI_SPDIF 1 x Power LED 1 x 8 pin 12V power
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Certification	FCC, CE, WHQL ErP/EuP Ready
Component for	PC
Motherboard chipset	AMD 770
Audio output channels	5.1 channels
Motherboard form factor	ATX
Motherboard southbridge	AMD SB710
Compatible operating systems	Windows 7 / 7 64-bit / Vista / Vista 64-bit / XP / XP Media Center / XP 64-bit
Supported storage drive interfaces	SATA
Parallel processing technology support	Not supported
LAN controller	Realtek RTL8111E
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	1.1
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	191 mm
Width	305 mm
