35
AMD X670/B650/A620 Series
VDDP Voltage
VDDP is a voltage for the DDR bus signaling (PHY), and it is derived from your DRAM
Voltage (VDDIO_Mem). As a result, VDDP voltage can approach but not exceed your DRAM
Voltage.
SoC/Uncore OC Voltage(VID)
Allows you to specify the SoC/Uncore voltage (VDD_SOC) to support memory and Innity
Fabric overclocking. VDD_SOC also determines the GPU voltage on processors with
integrated graphics.
VDD Misc Voltage
Allows you to congure the PCIe, DP Phy, PLL, ClkGen, and Pmux Supply.
DRAM VDDIO Voltage
Use this item to congure the VDDIO Voltage.
Seperate DRAM VDDIO Voltage Control
Allows you to congure the Seperate DRAM VDDIO Voltage control setting.
DRAM VPP Voltage
Allows you to congure the VPP Voltage supportewd by PMIC at DRAM side.
[Auto] Select this item to apply the default setting.
External Voltage Settings
Press [Enter] to congure the voltage options.
VDDCR_CPU Voltage
Input voltage for the processor by the external voltage regulator.
[Auto]
Select this item to apply the default VDDCR_CPU voltage setting.
[Oset Mode]
is mode allows you to congure the VDDCR_CPU voltage oset value.
[Fixed Mode]
is mode allows you to set a xed VDDCR_CPU voltage value.
VDDCR_CPU Load-Line Calibration
Load-Line is dened by Intel VRM Spec and aects the CPU power voltage. CPU Load-
Line Calibration helps prevent CPU voltage droop when the system is under heavy loading.
