ASROCK AMD A620 Series User Manual

37
AMD X670/B650/A620 Series
[Fixed Mode]
is mode allows you to set a xed VDDCR_SOC voltage value.
VDDCR_SOC Load-Line Calibration
VDDCR_SOC Load-Line Calibration helps prevent CPU voltage droop when the system is
under heavy load.
Conguration options: [Auto] [Level1]-[Level5]
VDDCR_SOC Auto Phase
Allows you to congure VDDCR_SOC Auto Phase.
[Enabled] Select this item to enable VDDCR_SOC Auto Phase support.
[Disabled] Select this item to disable VDDCR_SOC Auto Phase support.
VDDCR_SOC VR_HOT
Allows you to congure VDDCR_SOC VR_HOT.
VDDCR_SOC OTP Mode
[Enabled] Select this item to enable VDDCR_SOC OTP Mode.
[Disabled] Select this item to disable VDDCR_SOC OTP Mode.
VDDCR_SOC OTP Temperature
Allows you to congure VDDCR_SOC OTP Temperature.
VDD_MISC Voltage
Input voltage for the processor by the external voltage regulator.
[Auto]
Select this item to apply the default VDDCR_MISC voltage setting.
[Oset Mode]
is mode allows you to congure the VDDCR_MISC voltage oset value.
[Fixed Mode]
is mode allows you to set a xed VDDCR_MISC voltage value.
VDD_MISC Load-Line Calibration
VDD_MISC Load-Line Calibration helps prevent CPU voltage droop when the system is
under heavy load.
Conguration options: [Auto] [Level 1]-[Level 5]
