ASROCK AMD A620 Series - Page 49

45
AMD X670/B650/A620 Series
Upstream High Frequency Peak Port B
Allows you to congure the Upstream High Frequency Peak Port B settings.
Upstream Low Frequency Peak Port A
Allows you to congure the Upstream Low Frequency Peak Port A settings.
Upstream Low Frequency Peak Port B
Allows you to congure the Upstream Low Frequency Peak Port B settings.
Driver Swing
Allows you to congure the Driver Swing settings.
Conguration options: [Auto] [600 mVppd] [640 mVppd] [670 mVppd] [700
mVppd]
Flat Gain
Allows you to congure the Flat Gain settings.
Conguration options: [Auto] [-2.5 dB] [-1.5 dB] [-0.5 dB] [0.5 dB]
