1. Introduction
Thank you for purchasing ASRock B75M-DGS R2.0 motherboard, a reliable moth-
erboard produced under ASRock’s consistently stringent quality control. It delivers
excellent performance with robust design conforming to ASRock’s commitment to
quality and endurance.

step installation guide. More detailed information of the motherboard can be found
in the user manual presented in the Support CD.

updated, the content of this manual will be subject to change without no-


the latest VGA cards and CPU support lists on ASRock website as well.
ASRock website http://www.asrock.com
If you require technical support related to this motherboard, please visit

www.asrock.com/support/index.asp
1.1 Package Contents
ASRock B75M-DGS R2.0 Motherboard (Micro ATX Form Factor)
ASRock B75M-DGS R2.0
ASRock B75M-DGS R2.0 Support CD
2 x Serial ATA (SATA) Data Cables (Optional)
1 x I/O Panel Shield
English
ASRock Reminds You...
To get better performance in Windows
®
8 / 8 64-bit / 7 / 7 64-bit / Vista
TM
/
Vista
TM
64-bit, it is recommended to set the BIOS option in Storage Con-
  
Manual” in our support CD for details.
