8
ASRock B75M-DGS R2.0 Motherboard
English
CAUTION!
1. Intel
®
Small Business Advantage is a customizable platform in-
tegrated with IT tools, which helps maximize employee produc-
tivity, PC performance, and data security. There are applications
including Software Monitor, PC Health Center, Data Backup &
Restore, Energy Saver and USB Blocker.
2. Due to the operating system limitation, the actual memory size
may be less than 4GB for the reservation for system usage
under Windows
®
8 / 7 / Vista
TM
/ XP. For Windows
®
OS with 64-
bit CPU, there is no such limitation. You can use ASRock XFast
RAM to utilize the memory that Windows
®
cannot use.
3. Only PCIE1 slot supports Gen 3 speed. To run the PCI Express
in Gen 3 speed, please install an Ivy Bridge CPU. If you install
a Sandy Bridge CPU, the PCI Express will run only at PCI Ex-
press Gen 2 speed.
4. ASRock XFast RAM is not supported by Microsoft
®
Windows
®
XP / XP 64-bit. Intel
®
Smart Connect Technology and Intel
®
USB
3.0 ports are not supported by Microsoft
®
Windows
®
Vista
TM
/
Vista
TM
64-bit / XP / XP 64-bit.
