ASROCK B75M Quick Installation Guide

130
ASRock B75M Motherboard
- 60Hz’de 1920x1200’e kadar maks. зцzьnьrlьkle DVI’yэ
destekler
- 75Hz’de 2048x1536’ya kadar maks. зцzьnьrlьkle D-Sub’э
destekler
- Auto Lip Sync, Deep Color (12bpc), HDMI ile xvYCC ve
HBR’yi (Yьksek Bit Hэzlэ Ses) destekler (Uyumlu HDMI
monitцr gerekir) (bkz. DЭKKAT 9)
- DVI ve HDMI portlarэyla HDCP iюlevini destekler
- DVI ve HDMI portlarэyla Tam HD 1080p Blu-ray (BD) / HD-
DVD oynatэmэnэ destekler
Ses - 5,1 Kanal HD Ses (Realtek ALC662 Ses Codec’i)
- THX TruStudio
TM
desteği
LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/sn
- Realtek RTL8111E
- LAN’da Uyan özelliğini destekler
- LAN Kablo Algılama’yı destekler
- Enerji Verimli Ethernet 802.3az desteği
- PXE’yi destekler
Arka Panel G/З Paneli
G/З - 1 x PS/2 Fare Portu
- 1 x PS/2 Klavye Portu
- 1 x D-Sub Portu
- 1 x DVI-D Portu
- 1 x HDMI Portu
- 2 x Kullanэma Hazэr USB 2.0 Portu
- 4 x Kullanэma Hazэr USB 3.0 Portu
- 1 x RJ-45 LAN Portu, LED’li (AKT/LЭNK LED’i ve HIZ LED’i)
- HD Ses Jakı: Hat Girişi / Ön Hoparlör / Mikrofon
SATA3 - 1 x SATA3 6,0Gb/sn Intel
®
B75 konektör, donanım NCQ, AHCI
ve “Sistem Açıkken Bileşen Takma” işlevlerini
- 2 x SATA3 6,0Gb/sn ASMedia ASM1061 konektör, donanım
NCQ, AHCI ve “Sistem Açıkken Bileşen Takma” işlevlerini
USB 3.0 - 4 x Arka USB 3.0 bağlantı noktası, 5Gb/s’ye kadar USB
1.0/2.0/3.0
Konektör - 5 x SATA2 3,0Gb/sn, donanım NCQ, AHCI ve “Sistem Açıkken
Bileşen Takma” işlevlerini
- 3 x SATA3 6.0 Gb/sn konektör
- 1 x KÖ şi
- 1 x Kullanıcı Kızılötesi Modül Bağlantısı
- 1 x Yazdэrma Portu юi
- 1 x COM portu şi
Türkçe

ASROCK B75M Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
Supported memory module capacities	1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
Number of SATA II connectors	5
Number of SATA III connectors	3
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
HDMI version	1.4a
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Audio chip	Realtek ALC662
Cooling type	Passive
Certification	FCC, CE, WHQL, ErP/EuP Ready
Component for	PC
Power source type	ATX
Motherboard chipset	Intel B75
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7, Vista, XP 32/64-bit
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
Graphics card	GMA X4500
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1760 MB
Parallel processing technology support	2-Way CrossFireX, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
Controller 2nd interface type	ASMedia ASM1061
LAN controller	Realtek RTL8111E
Wi-Fi standards	Not supported
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	1.1
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	213 mm
Width	244 mm
