ASRock B75M Motherboard
1.2 Spesifikasi
Podium - Faktor Form Mikro ATX: 9.6-in x 8.4-in, 24.4 cm x 21.3 cm
- Desain All Solid Capacitor
CPU - Mendukung Intel
®
Core
TM
i7 / i5 / i3 Generasi Ke-3 dan Ke-2
dalam Paket LGA1155
- Desain daya 3+1 fase
- Menggunakan Teknologi Intel
®
Turbo Boost 2.0
- Mendukung CPU K-Series jenis “unlocked”
- Menggunakan Teknologi Hyper-Threading
- Mendukung Intel
®
Rapid Start Technology dan Smart
Connect Technology dengan Intel
®
Ivy Bridge CPU
Grup Chip - Intel
®
B75
- Menggunakan Intel
®
Small Business Advantage
Ingatan - Teknologi ingatan DDR3 dwisaluran
- 2 x Alur DDR3 DIMM
- Mendukung memori DDR3 1600/1333/1066 non-ECC yang
tidak di-buffer (DDR3 1600 dengan Intel
®
Ivy Bridge CPU,
DDR3 1333 dengan Intel
®
Sandy Bridge CPU)
- Kapasitas paling banyak: 16GB
- Mendukung Intel
®
Extreme Memory Prole (XMP)1.3/1.2
Alur Ekspansi - 1 x PCI Express 3.0 x16 slots (PCIE1: x16 mode )
* PCIE 3.0 hanya didukung dengan Intel
®
Ivy Bridge CPU.
Dengan Intel
®
Sandy Bridge CPU, hanya PCIE 2.0 yang
didukung.
- 1 x PCI Express 2.0 x16 slot (PCIE4: x4 mode)
- 2 x Alur PCI
- Mendukung AMD Quad CrossFireX
TM
dan CrossFireX
TM
Diagram * Intel
®
HD Graphics Built-in Visual dan output VGA hanya
dapat didukung dengan prosesor yang mengintegrasikan
GPU.
- Mendukung Intel
®
HD Graphics Built-in Visuals: Intel
®
Quick
Sync Video 2.0, Intel
®
InTru
TM
3D, Intel
®
Clear Video HD
Technology, Intel
®
Insider
TM
, Intel
®
HD Graphics 2500/4000
- Pixel Shader 5.0, DirectX 11 dengan Intel
®
Ivy Bridge CPU,
Pixel Shader 4.1, DirectX 10.1 dengan Intel
®
Sandy Bridge
CPU
- Ingatan sama Max. 1760MB
- Tiga pilihan VGA Output: D-Sub, DVI-D dan HDMI
- Mendukung HDMI 1.4a Technology dengan resolusi
maksimal hingga 1920x1200 @ 60Hz
Bahasa Indonesia

ASROCK B75M Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
Supported memory module capacities	1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
Number of SATA II connectors	5
Number of SATA III connectors	3
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
HDMI version	1.4a
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Audio chip	Realtek ALC662
Cooling type	Passive
Certification	FCC, CE, WHQL, ErP/EuP Ready
Component for	PC
Power source type	ATX
Motherboard chipset	Intel B75
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7, Vista, XP 32/64-bit
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
Graphics card	GMA X4500
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1760 MB
Parallel processing technology support	2-Way CrossFireX, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
Controller 2nd interface type	ASMedia ASM1061
LAN controller	Realtek RTL8111E
Wi-Fi standards	Not supported
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	1.1
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	213 mm
Width	244 mm
