Page #17 background imageLoading...
Page #17 background image
1717
1717
17
2.6 Expansion Slots (PCI and PCI Express Slots)2.6 Expansion Slots (PCI and PCI Express Slots)
2.6 Expansion Slots (PCI and PCI Express Slots)2.6 Expansion Slots (PCI and PCI Express Slots)
2.6 Expansion Slots (PCI and PCI Express Slots)
There are 1 PCI slot and 1 PCI Express slot on this motherboard.
PCI slot: PCI slot is used to install expansion card that has the 32-bit PCI interface.
PCIE slot: PCIE1 (PCIE x16 slot) is used for PCI Express card with x16 lane width
graphics card.
If you install the add-on PCI Express VGA card to PCIE1 (PCIE x16 slot),
the onboard VGA will be disabled. If you install the add-on PCI Express
VGA card to PCIE1 (PCIE x16 slot) and adjust the BIOS options “Primary
Graphics Adapter” to [Onboard] and “Share Memory” to [Auto], then the
onboard VGA will be enabled, and the primary screen will be onboard
VGA.
Installing an expansion cardInstalling an expansion card
Installing an expansion cardInstalling an expansion card
Installing an expansion card
Step 1. Before installing the expansion card, please make sure that the power
supply is switched off or the power cord is unplugged. Please read the
documentation of the expansion card and make necessary hardware
settings for the card before you start the installation.
Step 2. Remove the bracket facing the slot that you intend to use. Keep the screws
for later use.
Step 3. Align the card connector with the slot and press firmly until the card is
completely seated on the slot.
Step 4. Fasten the card to the chassis with screws.

Other manuals for ASROCK G41M-VS2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK G41M-VS2 and is the answer not in the manual?

ASROCK G41M-VS2 Specifications

General IconGeneral
Non-ECCYes
Number of memory slots2
Maximum internal memory8 GB
Processor socketLGA 775 (Socket T)
Processor manufacturerIntel
Compatible processor seriesIntel® Celeron®
Number of Parallel ATA connectors1
USB 2.0 ports quantity4
Firewire (IEEE 1394) ports0
Audio chipRealtek ALC662
CertificationFCC, CE
Power source typeATX
Audio output channels5.1 channels
Motherboard form factormicro ATX
Compatible operating systemsWin XP, Vista, 7
Maximum graphics card memory1759 MB
Networking features10/100 Mbps
BIOS memory size64 Mbit
Weight and Dimensions IconWeight and Dimensions
Depth170 mm
Width244 mm
