ASROCK G41M-VS2 User Manual

3232
3232
32
BIOS SETUP UTILITY
DRAM DLL SKEW Settings
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
OC Tweaker
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
DRAM CH0 CLKSET0 SKEW
[Auto]
DRAM CH0 CLKSET0 SKEW Info:11-5-1-0-0-1034
DRAM CH0 CLKSET1 SKEW
[Auto]
DRAM CH0 CLKSET1 SKEW Info:11-5-1-0-0-1034
DRAM CH0 CMD SKEW
[Auto]
DRAM CH0 CMD SKEW Info :3-4-1-1-0-311
DRAM CH0 CTRL0 SKEW
[Auto]
DRAM CH0 CTRL0 SKEW Info :0-5-1-1-0-55
DRAM CH0 CTRL1 SKEW
[Auto]
DRAM CH0 CTRL1 SKEW Info :2-3-1-1-0-211
DRAM CH0 CTRL2 SKEW
[Auto]
DRAM CH0 CTRL2 SKEW Info :2-3-1-1-0-211
DRAM CH0 CTRL3 SKEW
[Auto]
DRAM CH0 CTRL3 SKEW Info :2-3-1-1-0-211
DRAM CH1 CLKSET0 SKEW Info :11-5-1-0-0-1034
Auto
-350 ps
-300 ps
-250 ps
-200 ps
-150 ps
-100 ps
-50 ps
Normal
Options
DRAM DLL SKEW Settings
DRAM CH0 CLKSET0 SKEW
This controls the number of DRAM CH0 CLKSET0 SKEW. Configuration
options: [Auto], [Normal], [-350 ps] to [-50 ps]. The default value is [Auto].
DRAM CH0 CLKSET1 SKEW
This controls the number of DRAM CH0 CLKSET1 SKEW. Configuration
options: [Auto], [Normal], [-350 ps] to [-50 ps]. The default value is [Auto].
DRAM CH0 CMD SKEW
This controls the number of DRAM CH0 CMD SKEW. Configuration options:
[Auto], [Normal], [-350 ps] to [-50 ps]. The default value is [Auto].
DRAM CH0 CTRL0 SKEW
This controls the number of DRAM CH0 CTRL0 SKEW. Configuration options:
[Auto], [Normal], [-350 ps] to [-50 ps]. The default value is [Auto].
DRAM CH0 CTRL1 SKEW
This controls the number of DRAM CH0 CTRL1 SKEW. Configuration options:
[Auto], [Normal], [-350 ps] to [-50 ps]. The default value is [Auto].
DRAM CH0 CTRL2 SKEW
This controls the number of DRAM CH0 CTRL2 SKEW. Configuration options:
[Auto], [Normal], [-350 ps] to [-50 ps]. The default value is [Auto].
DRAM CH0 CTRL3 SKEW
This controls the number of DRAM CH0 CTRL3 SKEW. Configuration options:
[Auto], [Normal], [-350 ps] to [-50 ps]. The default value is [Auto].
DRAM CH1 CLKSET0 SKEW
This controls the number of DRAM CH1 CLKSET0 SKEW. Configuration
options: [Auto], [Normal], [-350 ps] to [-50 ps]. The default value is [Auto].
DRAM CH1 CLKSET1 SKEW
This controls the number of DRAM CH1 CLKSET1 SKEW. Configuration
options: [Auto], [Normal], [-350 ps] to [-50 ps]. The default value is [Auto].

ASROCK G41M-VS2 Specifications

General

Non-ECC	Yes
Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Compatible processor series	Intel® Celeron®
Number of Parallel ATA connectors	1
USB 2.0 ports quantity	4
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC662
Certification	FCC, CE
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Win XP, Vista, 7
Maximum graphics card memory	1759 MB
Networking features	10/100 Mbps
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	170 mm
Width	244 mm
