ASROCK H670M-ITX/ax User Manual

177
H670M-IT X/ax
Bahasa Indonesia
•
2 antena untuk mendukung teknologi ragam industri 2 (Transmisi)
x 2 (Terima)
•
Mendukung Bluetooth + Kecepatan tinggi kelas II
•
Mendukung MU-MIMO
I/O Panel
Belakang
•
2 x Port Antena
•
1 x Port HDMI
•
1 x DisplayPort 1.4
•
2 x Port USB 3.2 Gen2 (10 Gb/s) (Mendukung Perlindungan dari
ESD)
•
1 x USB 3.2 Gen2x2 Port Tipe C (20 Gb/s) (Mendukung
Perlindungan dari ESD)
•
4 x Port USB 2.0 (Mendukung Perlindungan dari ESD)
•
2 x Port LAN RJ-45 dengan LED (LED ACT/LINK dan LED
SPEED)
•
1 x Tombol BIOS Flashback
•
Soket Audio HD: Saluran Masuk/Speaker Depan/Mikrofon
Penyimpanan
•
4 x Konektor SATA3 6,0 Gb/s
•
1 x Soket Hyper M.2 (M2_1, Key M), mendukung PCIe tipe 2280
mode Gen4x4 (64 Gb/s)*
•
1 x Soket Hyper M.2 (M2_2, Key M), mendukung SATA3 tipe 2280
6,0 Gb/s & PCIe mode Gen4x4 (64 Gb/s)*
* Mendukung Teknologi Intel® Optane
TM
* Mendukung Intel® Volume Management Device (VMD)
* Mendukung SSD NVMe sebagai disk boot
* Mendukung Kit U.2 ASRock
RAID
•
Mendukung RAID 0, RAID 1, RAID 5 dan RAID 10 untuk
perangkat penyimpanan SATA
•
Mendukung RAID 0, RAID 1 dan RAID 5 untuk perangkat
penyimpanan M.2 NVMe
Konektor
•
1 x Header LED RGB
* Mendukung total Strip LED hingga 12V/3A, 36W
•
1 x Addressable LED Header
* Mendukung total Strip LED hingga 5V/3A, 15W
•
1 x Konektor Kipas CPU (4-pin)
* Konektor Kipas CPU mendukung kipas CPU dengan daya kipas
maksimum 1A (12W).

ASROCK H670M-ITX/ax Specifications

General

Processor socket	LGA 1700
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Maximum number of SMP processors	1
Ethernet LAN	Yes
LAN controller	Dragon RTL8125BG
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Ethernet interface type	2.5 Gigabit Ethernet
Audio chip	Realtek ALC897
Component for	PC
Motherboard chipset	Intel H670
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Number of M.2 (M) slots	2
Number of SATA III connectors	4
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
DisplayPort version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Maximum resolution	7680 x 4320 pixels
Parallel processing technology support	Not supported
BIOS type	UEFI AMI
ACPI version	6.0
BIOS memory size	128 Mbit
System Management BIOS (SMBIOS) version	2.7
Memory channels	Dual-channel
Memory slots type	DIMM
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	5000 MHz
Cables included	SATA
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
Harmonized System (HS) code	84733020
Weight	965 g

Weight and Dimensions

Width	170 mm
Height	70 mm
