1.4 Rear Panel

03











+'0,
'9,
'6XE

No. Description
12 DC-In jack
13 Optical S/PDIF Out port
14 Mic In (Pink): Microphone
15 Front L/R Out (Lime): Stereo speakers or headphones
16 USB 2.0 ports: USB devices
17 HDMI connector
18 DVI connector
19 VGA connector
20 USB 3.0 ports: USB devices
21 RJ-45 LAN port: Local Area Network
22 Line In (Blue) for 2/4/6 channel; Rear (Blue) for 8 channel
23 Center/LFE (Orange): Center / Subwoofer speakers
24 Side port for side speakers

ASROCK Mini Series Specifications

General

Model	ASRock Mini Series
Memory Type	DDR4 SODIMM
Power Supply	External Power Adapter
Processor	Varies by model (Intel or AMD)
Chipset	Varies by model (Intel or AMD)
Storage	Varies by model (M.2, 2.5" SATA)
Graphics	Integrated (Intel UHD Graphics, AMD Radeon Graphics)
Video Output	HDMI, DisplayPort
Networking	Gigabit LAN, Optional Wi-Fi
USB Ports	USB 3.2 Gen1, USB 2.0
Dimensions	Varies by model
Operating System	None (Barebone)
