7
English
Mini Series
1.5 Front Panel
No. Description
25 Optical Disc Drive
26 Power ON/OFF button with status indicator
27 Drive activity indicator
28 Headphone port
29 Microphone port
30 USB 3.0 ports: USB devices
31 Infrared receiver
31 30 29
28
27
26
25
