ASROCK Mini Series User Manual

11
English
Mini Series
Chapter 3 Reinstalling the ODD/HDD
1. Remove the cover screws on the rear panel. (For safety reasons, please ensure that the
power cord is disconnected before opening the case.
2. Slide the side cover toward the rear panel and pull the side cover upwards.
3. To change the storage drives, you need to remove the SATA and power cables from the
ODD / HDD rst, then unscrew the screws from both sides.

ASROCK Mini Series Specifications

General

Model	ASRock Mini Series
Memory Type	DDR4 SODIMM
Power Supply	External Power Adapter
Processor	Varies by model (Intel or AMD)
Chipset	Varies by model (Intel or AMD)
Storage	Varies by model (M.2, 2.5" SATA)
Graphics	Integrated (Intel UHD Graphics, AMD Radeon Graphics)
Video Output	HDMI, DisplayPort
Networking	Gigabit LAN, Optional Wi-Fi
USB Ports	USB 3.2 Gen1, USB 2.0
Dimensions	Varies by model
Operating System	None (Barebone)
