Battery installation eForce
®
150
Properly insert 4 (AA) Alkaline bat-
teries into battery holder observing
the polarity markings.
Plug battery pack into eForce
®
150
connector (FIG. 19).
Lithium batteries are suggested in
climates reaching 20°F and below.
Insert battery case into the eForce
®
150 as shown (FIG 20).
Slide battery cover over the batter-
ies.
A battery moisture shield is pre-
installed at the factory to protect the
batteries from the elements.
Insert 5/64” Allen key (included)
and turn clockwise two full turns to
secure the battery cover.
(FIG. 21).
FIG. 19
