Assa Abloy Alarm Controls KP-400 User Manual

3
Power Input
(12-24V AC/DC)
12 or 24 AC or DC. AC power can be connected
without observing polarity requirement. Connect DC
power with polarity as indicated.
Output 1, Output 2
SPDT dry contacts. Outputs can be programmed for
latching or momentary operation.
Egress Input
(EG IN)
A normally-open request to exit station can be
connected to this terminal and ground (-). Connecting
the terminal to ground will operated output 1 in the
same manner as a valid user code.
Key Active Output
(KEY ACT)
NPN transistor open collector output that switches to
ground (-) for 10 seconds with each key press. Output
rating Ic max: 100mA sink, Vc max: 24VDC.
Duress Output
(DU OUT)
NPN transistor open collector output that switches to
ground (-) after the duress code has been entered.
Output rating Ic max: 100mA sink, Vc max: 24VDC.
Door Position Sensor
Input
(DOOR SENS)
A normally-closed contact connected to this terminal
and ground (-) will provide a door position monitor. This
terminal must be connected to ground (-) if not used.
The factory installed jumper must be removed if using
this input.
Ground (-)
(GND)
System ground (-).
Output 1 Inhibit
(O/P 1 INHIB)
Normally-open input terminal used in a cross wire
connection in an interlock application.
Interlock Control Output
(INT. Lock)
NPN transistor open collector output that switches to
ground (-) for 5 seconds after entering a valid user
code. Use this output to control a second keypad in a
“Mantrap” application.
Normally-closed
Tamper
(Tamper N.C.)
Normally-closed output pair activated by the tamper
switch if the keypad faceplate is removed from the
back box.
WIRING
