Assa Abloy Aperio AH15 Installation Instructions

8
Physical Dimensions 82 mm x 82 mm x 37 mm (H x W x T)
Power Supply 8-24 VDC or Power over Ethernet (PoE)
Power Rating
Power supply
The power supply shall be able to deliver minimum
3.5 W. The power supply shall be 3 A over current
protected.
PoE
IEEE 802.3af compliant class 1 Powered device (PD)
Ethernet 10BASE-T / 100BASE-TX Local Area Network
Radio Standard
IEEE 802.15.4 (2400 – 2483,5 MHz)
16 channels (11-26)
15 channels in USA and Canada (11-25)
AES 128 bit encryption
Receiver Sensitivity -100 dBm
Wireless Transmit
Power
10 dBm/MHz according to EN ETSI 300 328.
Maximum spectral density.
Wireless Operating
Range
Indoors up to 25 m depending upon installed
environment.
Internal Antenna Two port cross polarized patch antenna.
External Antenna
One reverse polarity SMA external antenna
connector. AH40 is certified to be used with ASSA
ABLOY external antenna AH ANTENNA 1. If other
external antenna is used it must be of same type
(dipole) and not have larger antenna gain than
3,9 dBi.
Operating
Temperature
5 °C to 35 °C
Humidity < 95 % non-condensing
IP Classification IP20
Safety and
Emissions
FCC 47CFR Part 15 subpart B and subpart C
IC RSS-210
EN ETSI 301 489-17 v2.2.1
EN ETSI 300 328 v1.8.1
EN 60950-1 2006 / A11:2009 / A12:2011 / A1:2010
/ AC:2011
UL 294-2010
AH40 - Technical Data
