EN
Mounting
Mounting the counterpart
1 Prepare recess for the counterpart and all drilled holes.
2 Clean the recess and all holes by blowing or vacuuming them clean.
3 Screw in the counterpart for theescape door locking system 352M to be
installed.
· Adjust the rebate gap (“Product information”, page32) as required.
Use the supplied spacer plates and the SETLA M5 positioning plate
(“Mounting plate SETLA M5”, page56).
4 Check the door to ensure it moves freely.
 The escape door locking system 352M is ready for operation.
Checking the escape door locking system 352M
1 Check all functions of theescape door locking system 352M. Observe the
chapter on “Maintenance”, page56 when doing so.
 The escape door locking system 352M is completely installed and ready.
Having the mounting inspected and approved
1 Have a competent, qualified person inspect and approve the door.
