53
EN
Technical data
30
52,2
231,3
8
27
393
25
52
135
200
184
8
200
184
10
24
30
52,2
Escape door locking
system 352M
Striking plates on the lock
A
Attention!
Ensure the lock is correctly aligned to the counterpart:
When mounting, ensure that the reed contacts (
) for
the magnetic sensors are precisely aligned with each
other. otherwise, the sensor system will not work.
see note
