Technical data
Electrical data
Feature
Operating voltage
(controlled direct-current (DC)
voltage)
12 V . . . 24 V tolerance –15 % / +15 %
Supply voltage 10.1 V 12.0 V 24.0 V 28.0 V
Current consumption (locked) 360 mA 360 mA 190 mA 160 mA
Max. current consumption
for max. 2 s
620 mA 600 mA 290 mA 250 mA
Power consumption (locked) 4 W 4.5 W 5 W 4.5 W
Power consumption, maximum 6.5 W 7.5 W 7 W 7 W
Max. Max. contact loading
capacity for armature contact
25 V / 500 mA
Max. Contact rating of the door
contact
25 V / 100 mA
Fail-unlocked operating
principle
Ye s
