ASSA Profile Cylinders
TWIN V-10, TWIN EXCLUSIVE, TWIN PRO, TWIN MAXIMUM, CLIQ
Profile Cylinders
British Oval Profile Cylinders
Model No. Description TL A B C Comp Sub SNS
Twin V-10
V6531 61mm Large Single Cyl. 112.00 105.00 100.00
V6531 71mm Large Single Cyl. 112.00 105.00 100.00
V6531 81mm Large Single Cyl. 112.00 105.00 100.00
V6534 61mm Small Single Cyl. 100.00 93.00 88.00
V6534 71mm Small Single Cyl. 100.00 93.00 88.00
V6534 81mm Small Single Cyl. 100.00 93.00 88.00
V6532 61mm Double Cylinder 124.50 117.00 112.50
V6532 71mm Double Cylinder 124.50 117.00 112.50
V6532 81mm Double Cylinder 124.50 117.00 112.50
V6533 40.5mm Single Cylinder 100.00 93.00 88.00
V6533 45.5mm Single Cylinder 100.00 93.00 88.00
V6533 50.5mm Single Cylinder 100.00 93.00 88.00
Twin Exclusive
E6531 61mm Large Single Cyl. 112.00 105.00 100.00
E6531 71mm Large Single Cyl. 112.00 105.00 100.00
E6531 81mm Large Single Cyl. 112.00 105.00 100.00
E6534 61mm Small Single Cyl. 100.00 93.00 88.00
E6534 71mm Small Single Cyl. 100.00 93.00 88.00
E6534 81mm Small Single Cyl. 100.00 93.00 88.00
E6532 61mm Double Cylinder 124.50 117.00 112.50
E6532
71mm Double Cylinder 124.50 117.00 112.50
E6532
81mm Double Cylinder
124.50 117.00 112.50
E6533 40.5mm Single Cylinder 100.00 93.00 88.00
E6533
45.5mm Single Cylinder
100.00
93.00
88.00
E6533 50.5mm Single Cylinder 100.00 93.00 88.00
3.481 1.209 1.209 1.063
3.875 1.406 1.406 1.063
4.269 1.603 1.603 1.063
3.481 1.209 1.209 1.063
3.875 1.406 1.406 1.063
4.269 1.603 1.603 1.063
2.418 1.209 1.209 N/A
2.812 1.406 1.406 N/A
3.206 1.603 1.603 N/A
1.595 1.209 0.398 N/A
1.794 1.406 0.398 N/A
1.990 1.603 0.398 N/A
3.481 1.209 1.209 1.063
3.875 1.406 1.406 1.063
4.269
1.603
1.603 1.063
3.481 1.209 1.209 1.063
3.875
1.406 1.406 1.063
4.269
1.603
1.603
1.063
2.418 1.209 1.209 N/A
2.812
1.406
1.406
N/A
3.206 1.603 1.603 N/A
1.595 1.209 0.398 N/A
1.794 1.406 0.398 N/A
1.990 1.603 0.398 N/A
TL
ABC
Profile Cylinder Key:
TL
– Total Length
A – Exterior Length
B – Interior Length
C – Knob Length
